Inxpect Safety
Radar Equipment

The next generation safety products
modern technology that offers superior safety
Inxpect safety products are made for advanced industrial automation and robotics systems based on radar technology. Our products can detect the entrance and presence of operators in dangerous areas and stop machinery from restarting until the area is free of people, also in the presence of dust, debris, smoke and dirt.

The system automatically switches between the 2 safety functions:

switch-section.blocks.block1.image-alt
Access protection
System monitors the dangerous area:
  • OSSDs are in ON-state
  • Sensor sensitivity is low
  • Static objects are automatically excluded
  • Reaction time is 100ms
Area entered
angle
switch-section.blocks.block1.image-alt
Restart prevention
System scans the area for micro‑movements:
  • OSSDs are in OFF-state
  • Sensor sensitivity is high
  • Static objects are automatically excluded
  • System requires a restart timeout before switching back to access detection mode
Area cleared
angle
Smart Safety
Industrial safety at its best: Inxpect safety radars detect access or presence of operators in dangerous areas, allowing real-time dynamic setting of the detection and warning zones.

Inxpect Smart Sensors

World’s first and only SIL2/PLd and UL Listed safety radar products.
4m range sensor
S101A
The first safety radar sensor
5m range sensor
S201A
Symmetrical FOV
S201A-W
Advanced FOV
S203A-W
Vertical FOV 12°
9m range sensor
S201A-MLR
Symmetrical FOV
S201A-WL
Advanced FOV
S203A-WL
Vertical FOV 12°

Inxpect Control Units

The best interface to Inxpect safety radars for any type of machinery.
Type A
C201A-PNS
PROFIsafe
C201A-F
FSoE
C202A
MODBUS
C203A
USB
Type B
with SD card
C201B-P
PROFIsafe
C201B-F
FSoE
C202B
MODBUS
C203B
USB

Why choose Inxpect Safety Radar Equipment?

Inxpect Smart Sensors are resistant to any disturbances stemming from smoke, dust, shavings, sprays or machining residues.

The sensors can work at high sensitivity and can even detect the micro-movements of a person breathing to prevent accidental machine restart.

This radar intrinsically reads the space in 3D, providing volumetric coverage of the dangerous area.

Inxpect safety products are SIL2 certified, the most advanced safety level in the industrial sector.

whyRadar.mainimage.image-alt

Nothing has ever been this safe

in the industrial sector
Inxpect safety products adapt to many different usage situations in a wide range of working environments. Below are some of the most common usage scenarios, where radar technology has significantly increased safety levels.
Video poster Play video icon
Protection from access to dangerous areas

Find out how Inxpect safety products allow operators to work in total safety next to moving machinery

Video poster Play video icon
Anti-collision systems for bridge cranes

Find out how a bridge crane equipped with Inxpect safety products allow operators to work in areas where cranes are operating in total safety

Video poster Play video icon
Prevention of robot workcell restart

Find out how Inxpect safety products guarantee total safety for operators performing maintenance inside of a robotic workcell

Video poster Play video icon
Access Prevention to loading areas with independent motion systems (MIR)

Find out how Inxpect safety products guarantee safety even in highly automated environments
